The Audix TM2 is an all-in-one microphone and acoustic coupler for In Ear Monitor (IEM) test and measurement. It was designed specifically to allow live sound engineers to surmount the unique challenges of creating accurate and repeatable measurements of IEMs in the field, outside of laboratory conditions and equipment. Critically, IEM measurement requires a tight and consistent acoustic seal between the monitor and the coupler where even small variations can result in significant variance in the measurement. The TM2 is designed to surmount these issues and provide a means for accurate and repeatable IEM measurement, without the high cost of specialized laboratory grade equipment.
The base of the TM2 houses a built-in microphone element that connects to your audio interface using an XLR cable, and is supplied with phantom power from the mic preamp. The IEM is then inserted into the coupler and driven via the audio interface’s headphone output. Four adapters are included with the TM2, including “small” and “large” to accommodate standard stem sizes for universal-fit IEMs, a Custom Tip adapter, and an Ear Sim / Calibrator adapter. The Ear Sim adapter is similar to the typical “711” coupler that has traditionally been used for laboratory IEM measurements, and fits a standard ½” acoustic calibrator. The ability to calibrate the TM2 for SPL allows mix engineers to accurately measure the levels being delivered to the artist, helpful for consistency and important for the ability to characterize sound exposure risk.
- Durable, Compact, all-metal housing
- 3-year warranty
- rugged, milled aluminum enclosure
WHAT'S IN THE BOX?
- 1 TM2
- 4x Adapters: (1x) small-tip, (1x) large-tip, (1x) custom-tip, (1x) ear simulator
- 1x CaseTM2 – protective carrying case
- 3x Additional Foam Seals for the custom-tip adapter
|Transducer Type||Pre-polarized condenser|
|Frequency Response||20 Hz – 20 kHz|
|Output Impedance||200 Ohms|
|Sensitivity||Nom 6.5mV /Pa @ 1k (sensitivity for each unit included with calibration data)|
|Maximum SPL||130 dB|
|Signal to Noise Ratio||68 dB|
|Equivalent Noise Level||26 dB (A weighted)|
|Dynamic Range||104 dB|
|Power Requirements||24 – 48 V Phantom|
|Power Consumption||9 mA @ 48 Volts|
|Polarity||Positive pressure produces positive voltage on pin 2 relative to pin 3 of output XLR connector|
|Materials / Finish||Precision machined Brass and Aluminum / Nickel plating and Anodizing|
243 mm x 147 mm x 97 mm
